1 PCS UNIT Support MirrorLink + CARPLAY + Android Auto (SW:5406 C210)
1 PCS AV Camera Adapter(Gift)
1 PCS 2 To 1 FAKRA Antenna Adapter (Gift)
1 PCS Type-C cable
Skoda green light unit with rear USB
Package Include :
1 PCS UNIT Support MirrorLink + CARPLAY + Android Auto (SW:5406C210)
1 PCS AV Camera Adapter(Gift)
1 PCS 2 To 1 FAKRA Antenna Adapter (Gift)
1 PCS USB Switch Botton (Package A) or the other one (Package B)
1 PCS USB cable
1 PCS Type-C cable
*** Support Languages ***
English + Español
English+ русский
English+ Portugues
English+ Germany
-MIB UI RCD340 Plus, Radio Size Same As RCD510 (215mm*180mm*130mm).
– 6.5 inch color touch screen 800 x 480 pixel screen resolution
-AM 530-1600 KHz; FM 87.5-108 MHz -AM channels: 531, 540, 549 kHz…. in 9 kHz steps, In North America and Japan can not tuned in cleanly AM stations. However there is few poeple listen to AM boardcast. In Australia and europe no problem; FM channels: 87.5, 87.6, 87.7MHz…. in 0.1MHz steps which works in all counties.
-Radio Plug Size Same As RCD510 RCD310 RNS510. Standard VW Quadlock Socket.
-NO CD Changer. Unable to Play CD/DVD.
-Supports Bluetooth, USB, AUX, SD card, OPS, Rear View AV NTSC Camera, not vw RGB camera.
-Radio integrated BLUETOOTH hands free module + integrated microphone inside front panel.
-Supports All PQ 35/46 car makes.
1. Have vw RCD510/RNS315/ RNS510 plus vw original backup camera installed in your car. Reason is, vw original camera is RGB format whileas RCD330 works with AV camera only. Therefore, you have to buy RGB to AV converter, or replace backup camera, or give it up on backup camera.
2. Are a stickler for perfection.
3. Have Iphone Xs/Xr. Reason is when using handfree phone call via bluetooth, you can’t dial out on radio touchscreen, you can use SIRI via CarPlay to dial out. Other Iphones do not have such bug.
If you are not sure whether it is plug and play for your car make, please take pictures of your old radio+steering wheel and contact with me before purchasing.
– Support Android Auto/ CarPlay/Mirrorlink.
– Does Not Support RDS.
Radio Bluetooth Function Supports :
1. Show Phone Book On Touch Screen .
2. Call Phone Number on Radio
3. Add Favorite Phone Number
4. Show recent contacts
5. Play Bluetooth music -A2DP
Important notes:
– Radio supports steering wheel control,but only works with 12 button steering wheel;
– Doesn’t shown on dash maxi dot cluster;
– Doesn’t show skoda climate control.
-Car makes before 2009 maybe request a new gateway or need a Canbus adapter decoder simulatorto avoid battery drain;
-If your car has 8 button multi function steering wheel, you need to buy MFSW adapter, otherwise you can not control RCD330 plus.
By default the head unit is sent out with back-up camera function activated. If you need it deactivated please leave message when ordering.
Turn off the reversing camera function of the head unit without affecting the OPS (optical parking system) function.
Additional information
Original
Skoda Original, Original + Package A, Original + Package B, Package A+ Wireless carplay dongle, Package B + Wireless carplay dongle
